S764-1397 ,CADILLAC CTS V6-2.8L BRAKE SHOE, OEM04495-35250

S764-1397 ,CADILLAC CTS V6-2.8L BRAKE SHOE, OEM04495-35250
S764-1397 ,CADILLAC CTS V6-2.8L BRAKE SHOE, OEM04495-35250
OEM No/Model:

04495-35250

Minimum Order:

200Set/Sets

Export Ratio:

91% - 100%

Quality Certificate:

TS16949

Samples:

Free

Place of Region:

CHINA

Payment Terms:

T/T

Price Terms:

FOB

Delivery Port:

QINGDAO PORT

Delivery Time:

30DAYS

Market Type:

After Market

Packing:

COLOR BOXES AND PALLETS

Current Export Market:

North America,South America,Western Europe,Eastern Europe,Southeast Asia,Mid East,Africa,Oceania

Product Details

Product Name:

S764-1397 ,CADILLAC CTS V6-2.8L BRAKE SHOE, OEM04495-35250

Product Attribute:

Diameter:11.61inch

Width:1.97inch

Material:Carbon Steel

Application:

CADILLAC CTS V6-2.8L

Product Description:



FMSI Number - 764_1397
      04495-35250
Primary FMSI Spec.   OE Service
Drum Diameter - 11.610   11.610
Table Thickness - 0.079   0.077
Web Thickness - 0.177   0.176
Table Width - 1.970   1.988
Throat Dimension -
Outer Radius -

Friction Width - 1.970   1.985
Friction Thickness - 0.250   0.246
Friction Length - 11.630   11.688
No of Rivets if Riveted -     None

Secondary
Drum Diameter - Same   11.610
Table Thickness - Same   0.085
Web Thickness - Same   0.164
Table Width - Same   1.979
Throat Dimension -
Outer Radius -

Friction Width -     1.994
Friction Thickness -     0.246
Friction Length -     11.750
No of Rivets if Riveted -     None

**PRIMARY PIN**
Diameter:     0.343
Slot Diameter:     0.271
Slot Width:     0.083
Distance from shoe to
top of pin:
    0.702
**SECONDARY PIN**
Diameter:     0.227
Distance from shoe to
top of pin:
    0.386


S764-1397 ,CADILLAC CTS V6-2.8L BRAKE SHOE, OEM04495-35250
S764-1397 ,CADILLAC CTS V6-2.8L BRAKE SHOE, OEM04495-35250
